SpeedDome Optima delivers the standard features of a programmable dome, but is priced comparably to a PTZ.
This provides an alternative for customers who prefer the convenience and programmability of a dome camera,
but previously considered domes to be price-prohibitive.
And because the dome contains all of the necessary install components, installation is a breeze – just 15 minutes from box to Turnstile mount.
The dome’s power-on diagnostics and functional tests assist with fault isolation during install and service.
The dome accommodates a variety of protocols, including
RS-422/RS-485, Manchester and SensorNet,
making it compatible with any controller or matrix switcher/ controller system.
The dome features a color camera with 22x optical zoom (11x
digital) and 470 TV lines resolution, providing a quality, high-resolution
picture.
The dome also provides user-programmable presets and patterns, and contains one
alarm input and an auxiliary output.
Operational
Manual Pan/Tilt Speed . . . . . 1° to 50° per second (based on zoom position)
Preset Pan/Tilt Speed . . . . 100° per second, maximum
Pan Travel . . . . . . 360° continuous
Tilt Travel . . . . . . > 90°
Pan/Tilt Accuracy . . . . ± 0.5°
Zoom/Focus Accuracy . . . . . ± 0.5%
Optical Zoom . . . . . . . 22X
Digital Zoom . . . . . . . 11X
Bubble Density . . . . . . . . . . . Clear (f0.0) or smoked (f1.0)
Programmable Patterns . . . Three
Auto Synchronization
Line-Locked . . . Remote V-phase adjustment
Internal . . . . . . . Built-in sync generator
Address Range
RS-422/RS-485 . . . . . One to 96
Manchester . . . . One to 64
SensorNet . . . . . . One to 255
Alarm Inputs . . . . . . . . One (Optima only)
Auxiliary Relay
Outputs . . . . . . . . . . . . One (Optima only)
Electrical
Input Voltage . . . . . . . . . . . . .24 to 30 VAC, Class 2 LPS
Design Tolerance . . . . . 16 to 36 VAC
Line Frequency . . . . 50/60 Hz
Power Consumption
Indoor . . . . 21 W maximum
Outdoor . . . . . . 80 W maximum
Power-On In-Rush Current . . 3 A
Allowable Drop-Out . . . . 33 ms
Surge Protection
Video . . . . . . . Low-capacitance Zener suppressor of 6.5 V,
1500 W
SensorNet/Manchester . . Isolation transformer coupled, 2000 Vrms; PTC
resettable fuse protects transformer; TVS rated
at 5.6 V, 40 A, 0.1 J; 10 kA impulse rated gas
tube, 8/20 μsec impulse
RS-422/RS-485 . Series resistors of 33 Ω; TVS rated at 5.6 V,
40 A, 0.1 J (Optima only)
Resettable fuse, 0.6 A, 60 V, 1.2 Ω; 90 V, 10 kA
impulse rated gas tube (Optima LT only)
Alarm Input . . . . . . . . . . Series resistors of 33 Ω; TVS rated at 5.6 V,
40 A, 0.1 J (Optima only)
Auxiliary Output . 100 V isolation form 1-C relay (Optima only)
Power Line . TVS rated at 60 V, 250 A, 1.5 J; 10 kA impulse
rated gas tube, 8/20 μsec impulse
Camera
Imager . . . . . . . . . Interline transfer 1/4 in CCD array
Scanning System . . . . . 2:1 interlace
Video Output . . . . 1.0 Vp-p, 75 Ω composite
S/N Ratio . . . . . . . . 48 dB (typical)
Horizontal Resolution . . . . 470 lines at center
Minimum Illumination . 1.5 lux (20 IRE, AGC on)
Gain Control . . . . . . . . . . . . . Automatic (AGC)
White Balance . . . . . . . . . . . . Through the Lens (TTL) Automatic Tracing
White Balance (ATWB)
NTSC
Pickup Device . . 768 (H) x 494 (V) pixels
Scanning . . . . . . . . 525 lines, 60 fields, 30 frames
Horizontal . . . . . . . . . . . 15.734 kHz
Vertical . . . . . . . . . . . 59.9 Hz
PAL
Pickup Devices . . . 752 (H) x 582 (V) pixels
Scanning . . . . 625 lines, 50 fields, 25 frames
Horizontal . . . . . . . . . . . . . 15.625 kHz
Vertical . . . 50 Hz
Lens
Design . . Aspherical
Aperture . . . . . . . . f1.6
4 mm . . . . . . . . . 47.0° (H) x 35.2° (V)
88 mm . . . . . 4.0° (H) x 3.0° (V)
Focal Length . . . . . . . 4 to 88 mm
Field of View Formulas
Horizontal View = (.8 x A)/B
Vertical View = (.6 x A)/B
A = distance from camera in meters or feet
B = zoom power (e.g. 1-242x)
Mechanical
Dimensions (H x D)
In-Ceiling Model
Total . . . . . . . . 301 x 190.5 mm (11.9 x 7.5 in)
Above Ceiling . 207.4 x 190.5 mm (8.2 x 7.5 in)
Below Ceiling . . 92.7 x 178 mm (3.65 x 7.0 in)
Integral Pendant Housing Model
Total . . . . . . . . 303 x 243.5 mm (11.9 x 9.6 in)
Unit Weight
In-Ceiling Model . . . . 2.5 kg (5.5 lbs)
Integral Pendant Housing Model
Indoor . . . . . . . 2.7 kg (6.1 lbs)
Outdoor . . . . . . 3.0 kg (6.6 lbs)
Environmental
Weatherproof Standard
Outdoor Models . IP66/NEMA4
Operating Temperature
Indoor . . . . . . . -10° to 50°C (14° to 122°F)
Outdoor . . . . . -40° to 50°C (-40° to 122°F)
Humidity . . . . . . . . . . 0 to 95% RH (noncondensing)
Storage Temperature . -20° to 65°C (-4° to 149°F)
Wind Loading . . . . . Sustain winds of 240 km/hr (150 miles) when
properly installed and mounted (wall, pole, ceiling,
and over-the-roof mount with proper support).
(Outdoor model only)
Regulatory
Emissions . . . . . . . . . . . . . . . . FCC: 47 CFR Part 15,
Subpart B Class A
CE: EN55022 Class B
CE: EN6100-3-2
CE: EN6100-3-3
AS/NZS 3548, Class A
CISPR22
ICES-003
Immunity . . . . CE: EN50130-4
Safety . . . . . . UL: UL1950
CUL: CSA 22.2 No. 950
CE: EN60950
IEC950
