Click Pictures for Details and Pricing
High Security Series - Tandem Unit
(scroll down for pricing and access control components)

Dimensions/Drawings  |  3 Part Specs |  Installation Guides |  Data Sheets |  Wiring Diagrams |  Direction Sheet | AutoCAD - HS427 with Barcode with EntraPASS and KT300 Controller Schematic

www.TURNSTILES.us integrates the most reliable full-height turnstiles available. The High-Security Series units are engineered to meet all your security and control requirements, and are either stand-alone units, or part of an integrated system. Available in stainless steel, powder coat or a hot dipped galvanized finish, these units can be fitted for any application with access control technology and features.

Size Options (pedestrian clearance):
  Depth
(A)*
Width
(B)*
Passage Width
(C)*
Passage Height
(D)*
Overall Height
(E)*
HS427-T 54"
1327mm
94"
2388 mm
27"
686mm
84"
2134mm
91"
2311mm
HS430-T 56"
1422mm
102"
2591 mm
30"
762mm
84"
2134mm
91"
2311mm
* See CAD details for visual representation
Turnstile / Gate Timed-Release Button with Power Supply
Click for PDF Wiring Diagram
Part No.: PB24VDC-TimerRelay, $ 279.77 (each controlled direction)
AutoCAD - HS427 with Barcode with EntraPASS and KT300 Controller Schematic
Barcode or Proximity Card Access System
use with your existing cards
 works with Kronos, Dept. of Defense, Bureau of Prisons,  and all Barcodes & 26 Bit Prox Cards
Imports your existing Human Resources Database
www,AVLELEC.com EntraPASS



  • DOUBLE TURNSTILE ACCESS CONTROL KIT (DTAC)      $ 5,775.00
    Access control that has everything you need to minimize risk. Small and medium-sized organizations can benefit from access control just as much as large enterprises.

    Our Access Control Starter Kits make it easy to get started while our Expansion Kits enable your access control system to grow as you do.

    And that's important because with access control from www.AVLELEC.com, you'll be able to:

    Save money by avoiding the need to re-key your entire facility every time an employee or tenant leaves

    Improve your bottom line with better employee performance and punctuality by tracking time and attendance

    Reduce workplace hazards by keeping unauthorized personnel out of high risk areas

    When you get one of our Access Control Starter Kits, you get every component required to build an effective and reliable access control system.


    This includes:

    EntraPass Special Edition software (CD-ROM)

    (2) KT-300/128k door controllers

    (4) Four ioProx™ P225XSF readers

    (1) USB-485 converter

    (4) Two Form C relays 12V

    (2) 7 amp battery 16 VAC

    (2) 40 VA transformers
___________TURNSTILE CCTV RECORDING SYSTEM ___________

Includes 4 Outdoor Dome Cameras
Digital Motion Video Detection, Remote Viewing
Cabling, Connectors and Power Supplies are included
AutoCAD Point-to-Point Installation Schematics
Operation & Service Manuals

$ 5,306.00

(4)  Model MDC38
• Sony 1/3" CCD- Color • High Resolution Color Camera (480 TV Lines
• Low Sensitivity .5 Lux/F1.4 • Low consumption current • Super BLC Function • High Security Design & Clear Dome Housing • Easy Installation and Operation • 12VDC Power

(1) Model DVR411UN
4 Channel Stand Alone DVR, 30 IPS, TCP/IP Capable, Looping Outputs, USB Backup, 400GB Hard Drive



___________TURNSTILE CCTV RECORDING SYSTEM II ___________

Our Tera Series DVR can handle all of your cameras, at all of your locations
You can view every camera, at every facility with 1 DVR

• User-friendly operation - all it takes is a “click” on your mouse. OS / Windows XP Embedded

• Full Pentaplex Operation: View, Search Play, Record, Remote Access and Download data.

• Real time viewing up to 480 Frames per second (30 frames per camera)

• Real time recording 480 ~ 960 Frames. Adjustable recording speed setting and resolution for each individual camera

• Video Loss detection log, Alarm log, user access Activity Log. (All logged information retained for 3 years history, that tracks who did what, where and when)

• Simultaneous live view and search play on the same screen (AVEI Patent Applied feature)

• Multi-level user password access, total password protection (User Defined Custom Password Levels)

• RAID 5, 6. Hot-swap supported Storage capacity up to 8.25 TB using eleven removable Hard Drives.

• Video Resolution CIF, 2CIF and 4CIF in full screen Live view and Playback

• AVEI modified MPEG4 Compression algorithm average picture file size (1 KB ~ 4 KB).

• Selectable picture print size capability with up to eight pictures per page

• Backup archive to CDRW or DVDRW, Card reader and USB flash drive

• Playback Search by date, hour, minute, second, event alarm

• 16 Audio input and 16 Camera (Video) Loop out

• Lock feature on Critical recording file to avoid record overwrite
The Tera Series Digital Video Recorder represents the next generation of the finest performing Real Time DVRs. The software was designed based on the ideas and input from surveillance operators and business owners.  GVM 2000 (Global Video Management Server) will provide unlimited DVRs connections through the network. Now, you can create your own Command Monitoring Station in your office.



















•Motion Detection (User Definable) / Pre - Post Alarm
• Desktop, Wall or Rack Installation
• Smart search Playback (Object search) and Zoom Playback
• Preview functions and Preview Print functions
• Display Maps of facilities / POS Point of Sale - Programmable
• Recording Mode: Continuous, Motion Detection, Alarm (External Sensors), Time Lapse and Schedule Recording, Web View and Search (Playback) from Internet
• Ability to create a customized central command monitoring station
• Automatic remote notification to a central monitoring location of camera loss, malfunction or bad storage drives (Voice notification)
• Remote Access Software (GVM100)
• Multi-to-Multi Remote site-accessed PSTN, ISDN, DSL, T-1, E1, LAN, WAN, WIRELESS and INTERNET
• Motion Detection (User Definable) / Pre - Post Alarm • Desktop, Wall or Rack Installation
• Smart search Playback (Object search) and Zoom Playback
• Preview functions and Preview Print functions
• Recording Mode: Continuous, Motion Detection, Alarm (External Sensors), Time Lapse and Schedule Recording Web View and Search (Playback) from Internet
• Ability to create a customized central command monitoring station
• Automatic remote notification to a central monitoring location of camera loss, malfunction or bad storage drives (Voice notification)


To Order Call: 303.670.1099 ext.11
Patrick McAllister


High Security Double Turnstile, EntraPASS Card Access

HS427-T / HS430-T Tandem
Hot-dipped Galvanized finish shown
*Also available in stainless steel or powder coat finishes.

Matching full height manual passage gate available.
View High Security Single Turnstile

27" Passage Way
HS427-T-GV $   9,135.00
HS427-T-PC $ 10,096.00
HS427-T-SS $ 15,913.00

30" Passage Way
HS430-T-GV $   9,216.00
HS430-T-PC $ 10,178.00
HS430-T-SS $ 16,423.00

Part No. Codes
T-GV = Tandem - Galvanized
T-PC = Tandem - Powder Coated
T-SS = Tandem - Stainless Steel
----------------------------------------
Complete Galvanized System Pricing
Includes Barcode or Proximity Readers with EntraPASS Special Edition Access Control Software:


(1)   Tandem 2-Way Electric Turnstile with Card Access (in and out - both sides) with (4) Remote Emergency Push-Buttons at Guard Station

                       $ 16,029.00

Value-Added Service:

The following is included at no additional cost:

AutoCAD Device Location Detail, including cable routing and Electrical Requirements.

AutoCAD Point-to-Point Wiring Schematics

Low Voltage Cable, Plenum Rated

Unlimited Telephone Support
(until you are up and running)

5 Year Equipment Warranty

-----------------------------------------------------------
OPTIONAL INSTALLATION
(click for labor rates)

We have a team of field installers that will travel to your facility and perform the installation. Costs are:

(1) Erect Turnstile
     (cement platform and high
     voltage electrical by others)
    2 Men / 1 Day @ $ 75.17
     per man hour
     $ 1,202.72

(1) Wire Card Access System
     includes running cable from
     head-end to turnstile (within
     100 feet)
     installing readers on both
     sides of  turnstile, mounting
     KT300.
     2 Men / 1 Day @ $ 75.17
     per man hour
     $ 1,202.72

(1) Programming EntraPASS
     with your
     existing database (you will
     provide us
     prior to arriving your
     employee database
     in Excel, CSV, or Text File).
     1 Man / 3 Days @ $ 78.75
     per man hour
     $ 1,890.00

Travel and Accommodations are additional, and will be determined by your location.

Recent Installations
General Dynamics, Department of State, Robbins Air Force Base, Northrop Grumman.
